When illuminating a large, open space, a powerful high bay light is the go-to solution. But simply buying a bright fixture isn't enough; its performance is critically dependent on its mounting height. Installing a light too high or too low can lead to wasted energy, poor visibility, and even safety hazards. So, how high does a high bay light actually need to be? The answer isn't a single number but a careful balance of several key factors. This guide will walk you through everything you need to know.
What Is the Recommended Height Range for High Bay Lights?
Generally speaking, high bay lighting is designed for spaces with ceilings that are between 15 and 40 feet high. This broad range covers everything from a standard workshop or gymnasium to a large distribution center.
However, this is just a starting point. The ideal height within this range is not arbitrary. It depends on the specific characteristics of the light fixture, the requirements of the space, and the tasks being performed. The following factors will help you pinpoint the perfect mounting height for your specific application, ensuring optimal performance and efficiency.
4 Key Factors That Determine the Ideal Mounting Height
To get your high bay lighting right, you must consider these four interconnected variables. Getting the balance correct is the key to a successful lighting plan.
Factor 1: Ceiling Height - The Starting Point
Your ceiling height is the absolute maximum limit for your installation and the first number you need to know. The fixture itself will be mounted at, or suspended below, this height. This measurement immediately tells you whether you are in the high bay range (over 15 feet) or the low bay range (under 15 feet). All other calculations and decisions will be based on this primary dimension.
Factor 2: Lumen Output - Brightness Matters
Lumen output is the measure of a light's total brightness. The relationship is simple: the brighter the light (higher the lumens), the higher you can mount it while still achieving adequate illumination on the floor. A powerful LED high bay with 30,000 lumens can effectively light a surface from 30 feet up, whereas a 15,000-lumen fixture would be too dim at that height and is better suited for a 20-foot ceiling.
| Mounting Height | Recommended Lumen Output |
| 15 - 20 feet | 10,000 - 18,000 Lumens |
| 20 - 25 feet | 18,000 - 25,000 Lumens |
| 25 - 35 feet | 25,000 - 40,000 Lumens |
| 35+ feet | 40,000+ Lumens |
Tips: Lumen values are for reference only. Actual requirements may vary by application and lighting design. Contact us for professional guidance.
Factor 3: Application and Task Lighting Needs
The purpose of the space is a critical factor. Not all large areas have the same lighting requirements. For general warehouse lighting where employees are simply moving pallets, a moderate level of brightness (around 30 foot-candles) is sufficient. However, for an area with detailed assembly work or a quality control station, you will need much brighter, more focused light (70-100 foot-candles). Higher-demand tasks often require mounting the lights lower or using fixtures with a more focused beam.
Factor 4: Beam Angle - Directing the Light
The beam angle of a high bay light determines how the light spreads out from the fixture. Think of it like the nozzle on a hose. A narrow beam angle (like 60 degrees) concentrates the light into a powerful, focused beam, which is ideal for very high ceilings. A wider beam angle (like 120 degrees) spreads the light over a larger area with less intensity, making it suitable for lower mounting heights.
UFO vs. Linear High Bays: Does the Shape Affect Height?
The shape of the fixture also plays a role in its optimal placement, as it affects the pattern of light distribution.
UFO High Bays: Best for Open, Symmetrical Areas
A UFO high bay light is a round, compact fixture that produces a circular, cone-shaped beam of light. This makes it extremely efficient for illuminating large, open areas with high ceilings, such as gymnasiums, big-box retail stores, and open-plan warehouses. Their symmetrical light spread provides excellent, even coverage in square or round spaces.
Hyperlite LED High Bay Light - Black Hero Series, 21750lumens, Selectable Wattage&CCT, AC 120-277V
Linear High Bays: Ideal for Aisles and Rectangular Spaces
Linear high bay fixtures are long and rectangular, producing an elongated oval or rectangular pattern of light. This makes them the perfect choice for long, narrow spaces. In warehouse lighting, they are ideal for illuminating aisles between racking, as they direct the light down the aisle without wasting it by shining on top of the shelves. They are also excellent for long workbenches or assembly lines.
Linear High Bay LED Lights -HPLH01 Series, 18200lumens, Adjustable Wattage & CCT, 120-277V
Common Installation Mistakes to Avoid
Even with the right fixture, a poor installation can ruin your lighting plan. Be sure to avoid these common errors.
Installing Too High: Reduced Light Efficiency
If you mount a high bay light too high for its lumen output, the light will spread out too much by the time it reaches the floor. This results in dim, insufficient illumination (low foot-candles) and can make a space feel gloomy and unsafe.
Installing Too Low: Glare and Safety Issues
Mounting a powerful fixture too low is equally problematic. This can create intense "hot spots" of light and harsh glare, which is uncomfortable for workers and can be a serious safety hazard for forklift operators. It also leads to very uneven lighting.
Improper Spacing Leading to Dark Spots
The distance between fixtures is just as important as the mounting height. If lights are spaced too far apart, you will end up with a "checkerboard" effect of bright spots directly under the lights and dark, shadowy areas in between.
Ignoring Maintenance Access Requirements
Finally, consider how you will access the lights for cleaning or maintenance. Installing a fixture in a location that is extremely difficult to reach with a lift or ladder will make future maintenance a costly and time-consuming headache.
Conclusion
The right height of high bay lights is a very important element of a good and efficient lighting system. This is not really a matter of having a holy grail of numbers but rather understanding the ceiling height of the room and the lumens and beam angle of the fixture and the task that the room is occupied with. With good understanding and planning, and avoiding pitfalls, you could have a safe and well-lit environment that heightens the level of production and energy savings for a very long time.
FAQ
How far apart should I space my high bay lights?
The ratio of fixture spacing to mounting height is a useful guideline.
- General Illumination: For open areas, fixture spacing ≈ is 1.5 times the mounting height.
- Task-Oriented Lighting: For areas requiring brighter and more focused illumination, fixture spacing ≈ equal to the mounting height (1:1).
For more details about lighting layout, please contact us at sales@hi-hyperlite.com
What's the best color temperature (CCT) for a warehouse?
The recommended color temperature of industrial LED high bay lights spans between 4000k and 5000k, also known as neutral white and cool white colors. This color temperature is near the color of daylight and aids in enhancing alertness and eye comfort while also ensuring good color rendering of items stocked.
