Lighting Guide for Dairy, Poultry, and Hog Barns

Not all barns are the same. A lighting layout that works in a machine shed can fail quickly—or stress animals—inside a dairy, poultry, or hog building. Corrosive gases, humidity, dust load, and animal behavior all change what “good lighting” means.

This guide focuses on three common intensive-livestock environments:

• Dairy barns and parlors
• Poultry houses (broiler, layer, breeder)
• Hog barns (gestation, farrowing, finishing)

For each, you will see:

• Target illuminance ranges (lux) by task
• Practical fixture choices (form factor, IP/IK ratings, materials)
• Mounting and spacing rules of thumb
• Controls and dimming strategies that respect animal sensitivity
• Durability tactics for ammonia, dust, and washing

Throughout, the emphasis is on durable, verifiably compliant lighting—using standards like IEC 60529 for ingress protection (IP), IEC 62262 for impact ratings (IK), and test frameworks like IES LM-79 and IES LM-80 for LED performance and lifetime.

Because lighting affects safety and animal welfare, treat this guide as a technical starting point and pair it with your local code, veterinarian, and electrical professional.

---

1. Core Design Principles for Livestock Barn Lighting

1.1 Illuminance targets and visual tasks

Across livestock facilities, the starting point is always: what are people and animals doing in the space?

From field projects and industrial guidance such as ANSI/IES RP-7, a practical target range for barns is:

Area / Task	Typical Maintained Illuminance (lux)	Notes
General storage alleys, bedding areas	50–150	Basic navigation and monitoring
Animal work areas (milking, feeding rows)	150–300	Inspection, routine care
Detail / inspection (treatment stalls, vet areas, farrowing checks)	300–600	Fine visual tasks, injections, hoof checks

Use maintained illuminance—allowing for dirt and age depreciation. In real barns, lens dirt and ammonia exposure can cost 20–30% of initial lumen output over time. Designing to the top of each range usually avoids “too dark in year three” complaints.

A common mistake is to size lights off initial lumens alone. A better workflow is:

1. Decide required maintained lux at working plane (usually 0.8–1.0 m above floor).
2. Apply a lumen maintenance factor (e.g., 0.7–0.8 to account for LM-80/TM-21 behavior plus dirt).
3. Use photometric files (.ies per IES LM-63) in software like AGi32 to size quantity and spacing.

If you do not run software, a simple rule that works well for UFO or linear high-bay fixtures in barns is a spacing-to-mounting-height ratio of 1.0–1.5. For example, at a 14 ft (4.3 m) mounting height, center-to-center spacing of 14–21 ft maintains uniformity. In narrow aisles or high racking, 0.8:1 spacing keeps shadows under control.

For more detail on uniformity thinking, see the warehouse-focused guide on achieving lighting uniformity in a layout; the same principles apply to long barn alleys.

1.2 IP and IK ratings in real barns

Ingress Protection (IP) per IEC 60529 defines dust and water resistance. For livestock barns you should expect at least:

• IP65 or higher indoors: “dust-tight” and protected against low-pressure water jets.
• IP66 preferred where power-washing is routine, especially in hog and poultry rooms.

Impact rating (IK) per IEC 62262 is often overlooked. Gyms and parking structures use IK08–IK10 for ball strikes and vandal resistance; the same logic applies to:

• Low-mounted fixtures in dairy feed lanes where equipment can swing
• Hog barns with pen gates and feeders near fixtures

In practice, IK08+ (5 J impact) is a reasonable target for exposed fixtures. For a deeper dive into impact-resistant housings and lenses, the guide on high-impact vapor tight fixtures provides a detailed comparison.

1.3 Corrosive gases and material choices

Ammonia and hydrogen sulfide in livestock buildings attack metal hardware, drivers, and gaskets long before the LED chips wear out.

Two patterns show up repeatedly in field failures:

• Fixtures with good IP65 ratings still failing early because mounting hardware and external fasteners were mild steel, not stainless.
• Gaskets hardening or cracking in 2–4 years, letting moisture into the driver compartment.

To avoid this, prioritize:

• Stainless steel or coated mounting hardware and exposed fasteners.
• Replaceable gaskets or serviceable front covers.
• Powder-coated or anodized aluminum housings over bare or thinly painted metal.

Even with good materials, plan for 6–12 month cleaning cycles in dusty or high-ammonia rooms. Light output can drop 10–20% purely from dirt; combining cleaning with basic inspection extends real-world life significantly.

For an overview of how dust alone affects performance, the article on IP6X dust-tight fixtures for shops and barns is a useful companion reading.

1.4 Compliance and documentation

For commercial-scale barns, lenders, insurers, and inspectors often ask for documentation beyond a spec sheet. Three artifacts matter most:

• Safety listing: UL or ETL listing against luminaire standards such as UL 1598 (luminaires) and UL 8750 (LED equipment). You can verify listings directly in the UL Product iQ or Intertek ETL directory.
• Photometric performance: LM-79 test reports per IES LM-79-19 show lumens, lm/W, CCT, CRI, and power factor measured under controlled conditions.
• Lifetime evidence: LM-80 data and TM-21 projections per IES LM-80-21 and IES TM-21-21 connect “L70 @ 60,000 h” claims back to tested chip performance.

For new construction, energy codes such as ASHRAE 90.1-2022 and IECC 2024 govern allowable lighting power density and mandatory controls. In practice this means choosing high-lm/W fixtures and planning for occupancy or daylight control zones.

Finally, check your utility’s rebate rules. Many require high-bay or vapor-tight fixtures to be DLC-listed on the DesignLights Consortium Qualified Products List. That DLC listing is only granted when LM-79/LM-80/TM-21 documentation is complete, so it is an efficient way to filter out non-compliant products.

---

2. Dairy Barn Lighting: Parlors, Freestalls, and Youngstock

Dairy buildings combine wet conditions, frequent washing, and visually demanding animal-care tasks. The lighting design needs to support both human tasks and cow comfort.

2.1 Illuminance and color temperature for dairy

A practical set of targets for dairy facilities is:

Dairy Area	Maintained Illuminance (lux)	CCT (Correlated Color Temperature)
Milking parlors	200–400	4000–5000 K
Freestall alleys and feed lanes	100–200	4000–5000 K
Treatment / vet / calving pens	300–600	4000–5000 K
Utility rooms, chemical storage	150–300	4000–5000 K

Neutral-white 4000–5000 K generally provides good visual contrast for udder health checks and milking equipment cleanliness. Standards such as ANSI C78.377 define the acceptable chromaticity range for these CCT labels so that a “4000 K” from different manufacturers looks visually consistent.

Color rendering (CRI) above 80 is usually sufficient, but for herds where lameness and hoof issues are a focus, higher CRI can make subtle color differences easier to see.

2.2 Fixture selection and layout in dairy barns

In parlors and freestalls, the workhorse fixtures tend to be either:

• Linear vapor tights mounted along rows or
• UFO-style high bays mounted between or above stall rows

Key spec priorities:

• IP65–IP66 and corrosion-resistant housings; ammonia attacks unprotected steel quickly.
• Wide beam distributions (100–120°) to wash surfaces without harsh contrast.
• IK-rated lenses or guards where fixtures sit within reach of equipment.

For a typical freestall barn with 12–14 ft mounting height over alleys, a spacing-to-height ratio of 1.0–1.2 produces uniformity while keeping fixture count reasonable. Over feed lanes, shifting luminaires slightly toward the bunk face reduces animal shadows and makes ration evaluation easier.

In parlors, avoid placing fixtures directly over open water troughs or where they obstruct wash-down paths. Using two rows of fixtures, slightly offset from center, often balances uniformity with easy cleaning.

2.3 Controls and day–night strategies for dairy

Most dairy barns benefit from a clear day–night pattern. Cows rely on a consistent light–dark cycle, and abrupt changes can reduce production.

From operational experience:

• Use 0–10 V dimming or multi-level switching so you can ramp between “working” and “rest” levels.
• Aim for a night mode around 20–30% of daytime illuminance for routine checks without fully waking the herd.

Energy codes like ASHRAE 90.1-2022 also push toward occupancy or time-based control for non-animal spaces (office, milk room, utility). In practice, simple occupancy sensors in utility rooms and mechanical spaces can save 20–40% of lighting energy without affecting animal areas.

When you introduce sensors in barns, avoid basic PIR (passive infrared) units in dusty alleys or cow-movement zones; field experience shows they false-trigger or fail early. Enclosed microwave sensors or hardwired control zones generally hold up better.

For exterior yard and driveway lighting around the dairy complex, the separate guide on farm wall packs versus floodlights helps choose between perimeter wall packs and area floods.

---

3. Poultry House Lighting: Broilers, Layers, and Breeders

Poultry houses are some of the harshest environments for luminaires: very high dust load, aggressive ammonia, frequent high-pressure washing, and long rows that exaggerate any non-uniformity.

3.1 Optical performance and dimming in poultry

Poultry are highly sensitive to flicker, glare, and abrupt changes in light level. In broiler and breeder houses, lighting is part of flock management.

Practical parameters that work in many installations:

• General house illuminance: 20–60 lux at bird level during normal activity (varies by flock program).
• Inspection and catching modes: temporary boosts to 100–150 lux.
• Smooth dimming: 0–100% control with no visible steps or flicker.

The flicker point is critical. While mainstream safety regulations focus on radio interference (e.g., FCC Part 15), poultry operators look for drivers and dimming systems that avoid visible strobing that can startle birds. Consistent current regulation and drivers tested under LM-79 conditions help here.

3.2 Fixture construction for poultry houses

Here the extra information about corrosive gases matters most:

• Assume ammonia will reach every surface; painted steel hangers and screws usually corrode in 1–3 years.
• Use stainless or coated suspension kits and fasteners, and avoid thin wire hooks that can crumble.
• Choose fixtures with fully sealed wiring entries and replaceable gaskets so you can refurbish rather than scrap the whole unit.

An IP65 label alone is not enough. Real-world inspections often show:

• Condensation inside lenses where cable glands or conduit entries were not sealed.
• Early yellowing of low-grade polycarbonate lenses degrading light output.

A high-impact, UV-stabilized lens and IK08-class impact resistance give a more realistic lifetime in environments where birds, equipment, and personnel contact is frequent.

For mounting, keeping a spacing-to-height ratio around 1:1 along the house length and staggering rows sideways minimizes “banding”—bright and dark stripes that can affect bird behavior.

3.3 Controls and schedules in poultry

Poultry growers typically run defined light programs (ramp up, day period, ramp down) tailored to age and breed. Any lighting package must support:

• Low-end dimming below 5% without color shift.
• Slow ramps (e.g., 15–30 minutes) to change states without triggering panic behavior.

Industry education resources such as the NEMA Lighting Controls Association and its terminology guide LSD 64 are helpful for aligning vocabulary between growers, integrators, and electricians—terms like “fade time,” “scene,” and “setpoint” mean something specific in control systems.

Wireless or networked controls can simplify long-house retrofits, but barns with heavy metal cladding may need careful antenna placement. Always verify that any added control components retain appropriate IP ratings and are mounted outside the most corrosive zones where possible.

---

4. Hog Barn Lighting: Gestation, Farrowing, and Finishing

Hog facilities combine high moisture, manure gases, and frequent wash-down with the need for close visual inspection of animals—especially in farrowing and nursery rooms.

4.1 Illuminance needs by room type

Practical target ranges used in many hog projects are:

Hog Area	Maintained Illuminance (lux)
Finishing pens, general areas	50–150
Gestation and breeding pens	100–200
Farrowing rooms, piglet zones	200–400
Treatment / handling chutes	300–600

These values line up with “industrial task” ranges in documents like ANSI/IES RP-7, adjusted for the reality that walls and ceilings are often non-reflective or soiled.

Design to the upper end of each range; hog barn air quality and surface fouling usually reduce effective light levels over time.

4.2 Fixture robustness and placement in hog barns

Hog rooms push both IP and material durability:

• Choose IP66 where high-pressure wash is routine, especially in farrowing.
• Ensure all seals, glands, and joints can tolerate detergent and disinfectant exposure.
• Use stainless chains, hooks, and fasteners; budget for a 5% spare-parts kit (drivers, lenses, fasteners) to keep emitters in service while swapping components.

Placement tips from field installs:

• Avoid placing fixtures directly above feeders or where animals can contact them during rearing or loading.
• In farrowing rooms, a two-row layout—one row centered over sow crates, another over work aisles—delivers both animal and human visibility.
• Keep driver compartments accessible. In many retrofits, locating junction boxes or disconnects above an accessible walkway instead of directly over pens has cut maintenance time by 30–40%.

Hog barns also benefit from impact protection. IK08+ or a protective cage significantly reduces failures from accidental tool strikes or gate impacts.

4.3 Controls, sensors, and wiring in hog environments

In hog facilities, humidity and dust stress electronics as much as fixtures.

Sensor guidance from on-farm projects:

• Avoid open PIR sensors in dusty central alleys; they either false-trigger constantly or fail in 6–18 months.
• Prefer sealed microwave sensors in appropriate housings, or locate control hardware in cleaner service corridors.
• Use photocells for exterior yard and driveway lights, housed in suitable enclosures, to decouple outside lighting schedules from interior animal cycles.

Wiring and power distribution should follow the National Electrical Code as summarized in NFPA 70 guidance. For larger complexes, using higher distribution voltages (e.g., 347–480 V where permitted) reduces conductor size and voltage drop over long runs; local disconnects near equipment make servicing safer and faster.

---

5. Designing for Durability, Maintenance, and ROI

Livestock buildings are long-term assets. The lighting package should last through multiple equipment cycles, which means planning for performance, maintenance, and economics from day one.

5.1 Performance benchmarks and rebates

The U.S. Department of Energy’s Federal Energy Management Program (FEMP) provides a useful yardstick for efficient commercial and industrial luminaires. The guidance on purchasing high-efficiency luminaires sets minimum efficacy (lm/W) and performance factors for fixtures like high bays.

In practice, high-bay or vapor-tight fixtures in the 130–150 lm/W range and with good power factor routinely qualify for many utility rebate programs, provided they are listed on the DLC QPL. Combining DLC-listed fixtures with aggressive rebate programs can reduce simple payback from 5–6 years down to 2–3 years in many barn retrofits.

To quantify ROI, some farms integrate DSIRE data from the Database of State Incentives for Renewables & Efficiency into their project budgeting. DSIRE aggregates federal, state, and utility incentives and often reveals per-fixture rebates in the $30–$80 range for DLC-listed high bays and vapor tights.

5.2 Maintenance planning and spare parts

A frequent “gotcha” in barn projects is designing for perfect first-year performance but not for years three to ten.

A durable plan usually includes:

• Cleaning schedule: every 6–12 months, depending on dust and ammonia. Include lenses, housings, and sensor faces.
• Spare parts kit: stock around 5% of installed drivers, lenses, and fasteners on site, so a single failure does not sideline a whole row.
• Driver accessibility: fixtures or junction boxes positioned so an electrician can reach them from a catwalk or manlift outside pens.

Experience shows that designing for easy driver swaps can cut a typical repair visit from 60 minutes down to 20–30 minutes, especially when disconnects and terminations are out of the most corrosive areas.

5.3 Common misconceptions to avoid

A few myths show up repeatedly in barn lighting conversations:

• Myth 1: “Any IP65 fixture is fine for barns.”
  Reality: The IP code per IEC 60529 only addresses dust and water ingress, not ammonia corrosion or impact. Hardware, gasketing, and material selection often fail before the IP rating does.

• Myth 2: “LEDs last 100,000 hours no matter what.”
  Reality: TM-21, described in IES TM-21-21, specifically limits lifetime projections to six times the tested LM-80 duration. If a chip is only tested 6,000 h, claiming 100,000 h life is not supported. In barns with high temperature and corrosion, driver or gasket failure usually sets the real lifetime anyway.

• Myth 3: “Sensors do not belong in livestock barns.”
  Reality: Poorly chosen sensors fail; properly enclosed occupancy sensors and photocells, installed outside the most aggressive zones, perform reliably and save noticeable energy—especially in perimeter rooms, mechanical spaces, and exterior yards.

5.4 Example scenario: Retrofitting a mixed barn site

Consider a farm with:

• A 4-row freestall dairy barn (14 ft mounting height)
• Two tunnel-ventilated poultry houses (12 ft mounting height)
• A farrowing and finishing hog complex (10–12 ft mounting height)

A rational site-wide strategy could look like this:

1. Dairy barn: IP65–IP66 linear or UFO high bays at 1.2:1 spacing, 4000–5000 K, targeting 150–200 lux in alleys and 300+ lux in vet areas; 0–10 V dimming for night mode; simple manual or time-based control to preserve cow rest cycles.
2. Poultry houses: Fully sealed, corrosion-resistant fixtures with 0–100% smooth dimming; separate control system per house with programmed ramps and age-based schedules; IK-rated lenses and stainless suspension.
3. Hog complex: IP66 fixtures, IK08+ protection, driver locations in accessible service corridors; motion sensing in corridors and utility spaces; photocell-controlled yard lights outside.

By specifying DLC-listed, high-lm/W fixtures across all three building types, the farm can often bundle the project into a single rebate application, reducing upfront cost while standardizing maintenance and spare parts.

---

6. Practical Checklist Before You Specify Barn Lighting

Use this condensed checklist to review any dairy, poultry, or hog barn lighting package.

1. Define tasks and illuminance levels

   • Do you have target lux ranges by area (general, work, inspection)?
   • Have you factored in dirt and lumen depreciation (maintained vs initial)?

2. Confirm environmental ratings

   • Indoor fixtures at least IP65; IP66 where wash-down is routine.
   • Impact resistance (IK08+) where animals, equipment, or balls can strike fixtures.

3. Check corrosion resistance

   • Stainless or coated suspension hardware and fasteners.
   • Replaceable gaskets and sealed wire entries.
   • Housings suited for ammonia and high humidity.

4. Verify documentation and compliance

   • UL or ETL listing visible and verifiable in UL Product iQ or ETL directories.
   • LM-79, LM-80, and TM-21 data available when requested.
   • DLC listing on the DLC QPL if you plan to pursue rebates.

5. Plan controls and wiring

   • Are dimming and control strategies aligned with animal needs (smooth ramps, nighttime modes)?
   • Do occupancy/photo sensors have suitable enclosures and mounting locations?
   • Is wiring designed in line with NEC principles summarized in NFPA 70?

6. Design for maintenance

   • Driver and junction-box access outside pens where practical.
   • Cleaning schedule in operations plan (6–12 month intervals).
   • Spare-parts stock (around 5% of installed fixtures’ critical components).

7. Coordinate with stakeholders

   • Review plans with your veterinarian or animal welfare advisor.
   • Confirm energy-code and permitting requirements with your engineer or local authority.
   • Align lighting and controls with milking, feeding, and growth programs.

---

Frequently Asked Questions

What IP rating do I need for dairy, poultry, or hog barns?

For most interior livestock areas, IP65 (dust-tight, protected from low-pressure jets) is the minimum practical rating. In poultry and hog barns with frequent high-pressure washing, IP66 is strongly preferred. Remember that IEC 60529 IP codes do not cover corrosion, so also verify materials and hardware.

How often should I clean barn light fixtures?

In dusty or high-ammonia environments, a 6–12 month cleaning cycle is a realistic starting point. Some farrowing and poultry rooms benefit from cleaning at every flock or litter change. Combining cleaning with a quick gasket and hardware inspection keeps lumen output and lifetime close to what LM-79/LM-80 data suggest.

Can I use occupancy sensors in livestock barns?

Yes, but choose them carefully. Basic PIR sensors exposed to dust and animal movement tend to false-trigger and fail early. Sealed microwave sensors or wired control systems, located outside the harshest zones, perform much better. Follow NEC-aligned wiring practices as outlined in NFPA 70, and verify that all control components maintain appropriate IP ratings.

How do I know if a fixture is safe and compliant?

Look for a recognized safety mark (UL or ETL) and then verify the model in the UL Product iQ or Intertek ETL directory. For energy performance and rebates, check the DLC QPL to confirm that the specific model and wattage are listed under the correct category (high-bay, linear, or enclosed and gasketed).

What color temperature is best for livestock barns?

Most dairy, hog, and poultry barns perform well with neutral to cool white light in the 4000–5000 K range. According to ANSI C78.377, these CCT values correspond to specific chromaticity regions, which helps ensure different fixtures labeled “4000 K” or “5000 K” look similar in the space.

---

Safety and Compliance Disclaimer

This article is for informational purposes only. It does not constitute electrical, structural, veterinary, or legal advice. Livestock facilities involve significant safety, animal welfare, and regulatory considerations. Always consult a licensed electrician, qualified engineer, and relevant animal-health professionals, and follow local codes and standards before selecting or installing any lighting system.

Sources

• IEC 60529 – IP Ratings
• IEC 62262 – IK Ratings
• IES LM-79-19 – Optical and Electrical Measurements
• IES LM-80-21 – Lumen Maintenance Testing
• IES TM-21-21 – Lifetime Projections
• ANSI/IES RP-7 – Lighting Industrial Facilities
• ANSI C78.377-2017 – SSL Chromaticity
• ASHRAE 90.1-2022
• IECC 2024 – Commercial Energy Efficiency
• UL 1598 – Luminaires
• UL 8750 – LED Equipment for Lighting Products
• UL Product iQ Database
• Intertek ETL Listed Directory
• DesignLights Consortium – QPL
• DOE FEMP – Purchasing Energy-Efficient Commercial and Industrial LED Luminaires
• DSIRE – Database of State Incentives for Renewables & Efficiency
• NEMA Lighting Controls Association – Resources
• NFPA 70 – National Electrical Code Overview
