How do you calculate shop lighting?

How do you calculate shop lighting?

The first step would be to know the size of your room by measuring the space, you will need to get width, length and the ceiling height or you can determine what height you are planning to install the lights at. Then you can also get the square footage, you can multiply the length by the width to get it.
To obtain the minimum lumen value required for the room multiply the square footage (sq ft) by 70, as an example if your room is 30ft long by 40ft wide you would get 1,200 square feet, then multiplying this result by 70 you would get 84,000 Lumens as the minimum value required to lit that space up, so for this example if you are planning to use this room as a storage area and not much light is required, this is the minimum lighting required. If the ceiling height would be determined at 15ft high then you could use just 4pcs 150w Hero Series 21,000 Lumens equals 84,000 Lumens required and obtain 47fc on the floor. If you were planning to use this same room for detailed work you would need to multiply the square footage value by 105 and roughly get the Lumens value, in this case it would be 126,000 Lumens, so in that case you would need to use 6pcs 150w Hero Series 21,000 Lumens equals 126,000 Lumens.

As a good example Hyperlite offers three types of UFO High Bay LED Lights, Hero Series, Tale Series and Apollo Series, the three of them are dimmable and come with the round pattern 120 degree beam angle these UFO High Bay LED Lights are better recommended for open spaces. Hero Series, Tale Series and Apollo Series, are available in different wattages, 100w, 150w, 200w and 250w. Hyperlite recommends 100w for ceilings from 10ft to 13ft high, 150w is recommended for ceilings between 14ft to 17ft, 200w for ceilings from 18ft to 20ft and 250w is recommended for 21ft ceilings or higher. Hero Series, Tale Series and Apollo Series, come with the US hook, so they can be directly hung using an eye bolt on a rafter, securing them with the provided safety cable. Hero Series, Tale Series and Apollo Series, come with a standard 110v plug and Tale Series is just ready for hard-wiring.

The easiest way to know how many lights and what size or wattage you would need is to call Hyperlite toll free number (+1-855-688-7879) or send us an email to service01@hi-hyperlite.com, provide them with the size of your room including the ceiling height and they will work on a recommendation or layout that will be sent to your email the same day.
