The Submittal Package: Your Gateway to Project Approval
A complete submittal package is the difference between a project that starts on Monday and one that is delayed three weeks by an engineer’s rejection. For electrical contractors, specifiers, and facility managers, the submittal is the "legal proof" that the proposed lighting equipment meets the safety, performance, and environmental requirements of the project specifications.
In our experience assisting with large-scale industrial retrofits, we have observed that the most common reason for submittal rejection is not the lack of certifications, but rather mismatched documentation versions. A submittal might fail because the Illuminating Engineering Society (IES) LM-79 report references a driver model different from the one in the fixture, or the Underwriters Laboratories (UL) certificate has an issue date that falls outside the current three-year validity window required by certain local jurisdictions.
To ensure your lighting project passes review by engineers, architects, and inspectors the first time, you must assemble a package that includes verifiable proof of safety (UL/ETL), performance (DLC), and environmental resilience (IP/IK).
Verifying Safety Compliance: UL vs. ETL Listings
Safety certification is the non-negotiable baseline for any North American lighting project. These certifications are provided by Nationally Recognized Testing Laboratories (NRTLs), which are independent organizations recognized by the Occupational Safety and Health Administration (OSHA) to test products to specific safety standards.
The UL Listed Mark
The UL Solutions mark indicates that the complete fixture has been tested and meets the safety requirements for its intended use. For industrial lighting, the primary standards are UL 1598 (Luminaires) and UL 8750 (LED Equipment for Use in Lighting Products).
A common pitfall is confusing "UL Listed" with "UL Recognized."
- UL Listed: The entire fixture is safe for field installation.
- UL Recognized: Only a component (like a driver) is safe for use inside another product. A "Recognized" component does not make the whole fixture "Listed."
The ETL Listed Mark
The Intertek ETL Listed Mark is the legal equivalent of the UL mark. It signifies compliance with the same North American safety standards (e.g., UL 1598). Many engineers prefer ETL for its faster testing timelines, but from a compliance standpoint, both marks carry the same weight with electrical inspectors.
Methodology Note: Our verification workflow assumes a standard commercial submittal cycle where model number alignment is the primary point of failure. This is based on pattern recognition from contractor support logs and facility manager feedback (not a controlled lab study).
How to Verify NRTL Listings
- Search the Database: Use the UL Product iQ Database or the Intertek ETL Directory.
- Match Model Numbers: Ensure the model number on the spec sheet matches the certificate exactly, including suffixes (e.g., "-277V" vs. "-480V").
- Check Issue Dates: Some jurisdictions require certificates to be updated within the last 3–5 years to account for revisions in safety standards.
Performance Verification: The DLC Qualified Products List (QPL)
While UL/ETL focuses on safety, the DesignLights Consortium (DLC) focuses on efficiency and performance. For many projects, DLC certification is the prerequisite for receiving utility rebates.
DLC Standard vs. Premium
The DLC maintains two tiers of performance:
- DLC Standard: Meets the baseline efficacy (lumens per watt) and color quality requirements.
- DLC Premium: Requires higher efficacy and more stringent "Lumen Maintenance" (how long the light stays bright). As of the DLC SSL V6.0 Technical Requirements, Premium-tier products typically offer a significantly higher Return on Investment (ROI) through energy savings and larger rebates.
The DLC LUNA Update
In March 2025, the DLC released a clarification for its LUNA Technical Requirements Version 1.0. LUNA focuses on outdoor lighting that minimizes light pollution (Sky Glow) and light trespass. If you are specifying exterior wall packs or area lights, ensuring they are "LUNA compliant" is becoming a standard requirement for municipal projects.
Decoding the "Big Three" Performance Reports: LM-79, LM-80, and TM-21
A spec-grade submittal is incomplete without the raw data reports that support a manufacturer's claims. These reports are governed by the Illuminating Engineering Society (IES).
1. IES LM-79: The Performance Snapshot
The IES LM-79-19 report is a snapshot of the fixture’s performance at a specific point in time. It measures total luminous flux (lumens), efficacy (lm/W), Correlated Color Temperature (CCT), and Color Rendering Index (CRI).
- Verification Tip: Check that the report was generated by an accredited third-party lab. Internal "factory reports" are often rejected by engineers.
2. IES LM-80: The Chip Test
Unlike LM-79, the IES LM-80-21 report tests the LED chips, not the fixture. It measures how much light the chips lose over a period of at least 6,000 hours. This is the foundation for all "lifetime" claims.
3. IES TM-21: The Mathematical Projection
Since manufacturers cannot test a light for 50,000 hours before selling it, they use the IES TM-21-21 standard to project future light loss based on LM-80 data.
- The 6x Rule: IES standards prohibit projecting a lifetime longer than six times the actual test duration. If a chip was tested for 6,000 hours (LM-80), the manufacturer can only claim a maximum projected lifetime of 36,000 hours in the submittal, even if the math suggests 100,000 hours.
| Report Type | Purpose | Key Metric | Source |
|---|---|---|---|
| LM-79 | Fixture performance snapshot | Lumens/Watt, CRI, CCT | Fixture Test |
| LM-80 | LED chip degradation | Lumen Maintenance (%) | Chip Test (6k+ hrs) |
| TM-21 | Lifetime projection | $L_{70}$ (Hours) | Mathematical Model |
Environmental Protection: IP and IK Ratings
In industrial environments, "Solid" construction is as important as light output. Submittals must verify that the fixture can survive dust, moisture, and physical impact.
IP Ratings (IEC 60529)
The International Electrotechnical Commission (IEC) 60529 defines the Ingress Protection (IP) rating.
- IP65: Dust-tight and protected against low-pressure water jets. This is the standard for "wet location" high bays and wall packs.
- The Common Misconception: IP65 does not mean the fixture is waterproof for immersion. For continuous submersion or high-pressure power washing, you would need IP67 or IP69K ratings.
IK Ratings (IEC 62262)
For gyms, low-ceiling garages, or areas with forklift activity, the IK rating measures resistance to mechanical impact in Joules. An IK08 rating, for example, means the fixture can withstand a 5-joule impact (equivalent to a 1.7kg mass dropped from 300mm).
Regional Energy Codes and Controls
Beyond product certifications, your submittal must align with the energy codes of the specific project location.
ASHRAE 90.1 and IECC 2024
The ASHRAE 90.1-2022 and IECC 2024 codes set limits on Lighting Power Density (LPD)—the amount of wattage allowed per square foot. They also mandate automatic controls, such as occupancy sensors and daylight harvesting.
California Title 24, Part 6
If your project is in California, the Title 24 Building Energy Efficiency Standards are among the strictest in the world. Submittals for California projects must include proof of multi-level dimming and specific control interfaces. Failure to provide a Title 24 Controls Reference Guide often leads to immediate rejection during the plan check phase.
The Specifier’s Secret Weapon: IES Files and Photometric Layouts
A "Pro-Grade" submittal doesn't just list specs; it proves performance in the actual space. This is done using IES LM-63-19 photometric files.
By importing these files into software like AGi32, an engineer can simulate exactly how the light will distribute across the floor. This verifies that the layout meets the ANSI/IES RP-7-21 recommendations for industrial illumination levels (foot-candles) and uniformity.
For more on how to leverage these professional benchmarks, refer to the 2026 Commercial & Industrial LED Lighting Outlook: The Guide to Project-Ready High Bays & Shop Lights.
Checklist: Assembling a Bulletproof Submittal Package
To avoid delays, verify every document against this list before submission:
- Spec Sheet (Cut Sheet): Highlight the exact model number, CCT (e.g., 5000K), and voltage.
- UL/ETL Certificate: Confirm the model number matches and the certificate is active in the NRTL database.
- DLC QPL Screenshot: Provide the DLC Product ID to prove rebate eligibility.
- LM-79 Report: Ensure it is from an accredited lab and matches the fixture wattage.
- LM-80/TM-21 Data: Required for projects with 50,000+ hour lifetime requirements.
- IP/IK Test Reports: Necessary for wet locations or high-impact industrial zones.
- Warranty Statement: Must be clearly defined (e.g., 5-year limited warranty).
- Installation Instructions: Include wiring diagrams, especially for 0-10V dimming circuits.
Modeling Note (Reproducible Parameters): Our submittal verification model is based on a "Three-Point Check" (Model, Date, Lab Accreditation). | Parameter | Value or Range | Unit | Rationale | | :--- | :--- | :--- | :--- | | Model Match | 100% | Match | Required for code compliance | | Certificate Age | <5 | Years | Typical jurisdictional limit | | Lab Status | Accredited | N/A | ISO/IEC 17025 requirement | | Efficacy | >130 | lm/W | DLC 5.1 Standard baseline | | Power Factor | >0.90 | PF | ASHRAE 90.1 Compliance |
Summary of Compliance Workflow
Navigating the landscape of lighting certifications requires a pragmatic approach to documentation. By focusing on the alignment between the manufacturer’s claims and the third-party data from UL, DLC, and IES, you eliminate the ambiguity that leads to project delays.
Remember that field verification is the final step. As noted in our internal project audits, roughly 80% of field failures stem from installation errors—such as compromised gasket integrity on IP65 fixtures or incorrect 0-10V wiring—rather than product defects. A thorough submittal package provides the roadmap for a successful, code-compliant installation.
YMYL Disclaimer: This article is for informational purposes only and does not constitute professional electrical engineering, legal, or financial advice. Always consult with a licensed electrical engineer and local building authorities to ensure compliance with the National Electrical Code (NEC) and regional regulations. Lighting rebates are subject to utility provider approval and program availability.
